5x5m Gazebos, Marquees & Pop Up Tents
Available Frames
Print Package 1
$4,295
Print Package 2
$4,495
Print Package 3
$4,495
Print Package 4
$4,995
Specifications: Aluminium Frame & Connectors | Hexagonal Shape Main Profile | Leg Profile 57x 50 x 2mm | Truss Bars 36 x 18 x 2mm | Height 4.09m | Clearance 2.05m | Frame Weight70kg | Poly Roof Weight 16kg | Box Dimensions 173 x 62 x 61cm
Warranty: Frame 10 Years | Polyester Fabric 1 Year | UV Fabric 2 Years | PVC Fabric Plain 5 Years | PVC Fabric Printed 2 Years
Resources: Specification Sheet | Artwork Template | Instruction PDF | Instructions Video | Engineer Cert | Fire Retardant Report Poly | Fire Retardant Report PVC | Water Penetration Report | UV Protection Report Poly | UV Protection Report PVC
Custom Printing
We offer custom printing on a wide range of products. Don’t forget to checkout our available print packages!
Print Package 1
1 x Valance Panel Print
Print Package 2
4 x Valance Panel Print
Print Package 3
1 x Valance Panel Print
1 x Roof Panel Print
Print Package 4
4 x Valance Panel print
4 x Roof Panel Print
Print Package 1
1 x Valance Panel Print
Print Package 2
4 x Valance Panel Print
Print Package 3
1 x Valance Panel Print
1 x Roof Panel Print
Print Package 4
4 x Valance Panel print
4 x Roof Panel Print
Sublimation Printing
Sublimation printing, also known as dye sublimation printing involves the use of a digital printer to produce a print on sublimation transfer paper. The sublimation paper is then placed into a heat press with the marquee fabric and exposed to a temperature of 200 degrees celsius. The artwork is then transferred from the paper to the marquee fabric.
600D PU Coated Polyester, Fabric 245GSM, Sewn with Fabric Binding, Matte print finish.
LED-UV Printing
UV printing is a form of digital printing that uses ultra-violet lights to dry or cure ink as it is printed. As the printer distributes ink on the surface of the marquee fabric, specially designed UV lights follow close behind, “curing” or “drying” the ink instantly.
900D PU Coated Polyester, Ultra-violet light printing, Sewn with fabric binding, Clear protective seal, Print finish semi gloss.
Digital Printing
Large format digital printing refers to method of printing from a digital based image directly to the PVC marquee material.
Once the print has dried a hot lacquer is applied to the print surface to seal the print to avoid scratches.
580gsm PVC, Large format digital printing, Heat welded seams, Hot lacquer, Print finish glossy
Compare Fabrics
500D PVC Coated Polyester
Available for Plain products
Specifications
100% Polyester with PVC backing
Yarn count: 500D x 500D
Weight: 280 gsm
Colourfastness to light 5-6 En
Features
1 year warranty
Waterproof
Fire, UV & Wind resistant
PVC reinforced Corners
600D PU Coated Polyester
Available for Custom Printed products
Specifications
100% Polyester with PU backing
Yarn count: 600D x 600D
Weight: 245 gsm
Colourfastness to light 5-6 En
Features
1 year warranty
Fire, UV and wind resistant
Waterproof
PVC Reinforced Corners
Black or White reverse fabric
Dye Sublimation Printing
Dye sublimation printing involves the use of a digital printer to produce a print on sublimation transfer paper. The sublimation paper is then placed into a heat press with the fabric and exposed to a temperature of 200 degrees Celsius. The artwork is then transferred from the paper to the fabric. The fabric has the artwork embedded in the material and the design will not scratch from the surface. The fabric has a matte finish, which photographs well and suits indoor and outdoor use.
580 GSM PVC
Available for Plain and Custom Printed products
Specifications:
100% PVC
Weight: 580 gsm
Colourfastness to light: 5-6 En standard
Features:
2 year warranty printed
5 year warranty plain
Waterproof
Fire, UV & Wind resistant
Hot lacquer welded seams
Digital Print Process
Large format digital printing refers to method of printing from a digital based image directly to the PVC material. Once the print has dried a hot lacquer is applied to the print surface to seal the print to avoid scratches.
Print Packages
Marquee Wall
Enhance your Folding Marquee with custom or plain walls!
Marquee Accessories
Enhance your Folding Marquee with accessories and weights!
Promotional Products
Ready to find out more?
Extreme Marquees offers a wide range of high-quality marquees, including the 5m x 5m size in the X7 Tectonic series. The X7 Tectonic series is a top-of-the-line marquee range that has been designed for professional use and demanding applications. The 5m x 5m marquee from this range is perfect for outdoor events and functions, providing ample space for guests or equipment while also protecting them from the elements.
The X7 Tectonic series marquees are built to last, featuring a heavy-duty 50mm hexagonal aluminium frame that is both strong and durable. This frame is reinforced by an inner leg and cross-bracing system that provides additional support and stability, ensuring that the marquee can withstand even the toughest weather conditions. The roof is made from high-quality PVC-coated polyester, providing superior protection from the sun, rain, and wind.
One of the standout features of the X7 Tectonic series marquees is the ease with which they can be set up and taken down. The frame is designed to be simple and intuitive to assemble, with a unique spring system that allows the roof to be attached easily and securely. The marquee also features adjustable legs, which make it easy to set up on uneven surfaces, as well as commercial-grade foot plates that provide a solid foundation.
Another advantage of the 5m x 5m marquee from Extreme Marquees is its versatility. The marquee can be customised with a range of accessories, including side walls, awnings, and branding packages. This means that you can tailor the marquee to your specific needs, whether you are hosting a corporate event or a private party. The branding packages, in particular, offer an excellent opportunity to promote your business or organisation, with custom-printed logos and graphics that will make your marquee stand out from the crowd.
In addition to its impressive features and versatility, the 5m x 5m marquee from Extreme Marquees is also backed by a comprehensive warranty. This gives you the peace of mind that comes with knowing that your investment is protected, and that you can rely on your marquee to perform for years to come.
Overall, if you are looking for a high-quality, versatile, and durable marquee for your outdoor event or function, the 5m x 5m size from Extreme Marquees’ X7 Tectonic series is an excellent choice. With its heavy-duty frame, easy assembly, and customisable options, this marquee is sure to meet all your needs and exceed your expectations.
