Printed Marquee Packages
Available Frames
Specifications: Steel Frame | Nylon Connectors | Hexagonal Shape Main Profile | Leg Profile 45 x 40 x 1mm | Truss Bars 30 x 15 x 1mm | Height 3.29m | Clearance 2m | Frame Weight 27kg | Roof Weight 9kg | Box Dimensions 163 x 236 x 27cm
Fabric: Plain Polyester Fabric 500D PVC Coated or Printed Polyester Fabric 600D PU Coated
Warranty: Frame 1 Years | Fabric 1 Year | UV Fabric 2 Years
Resources: Specification Sheet | Artwork Template | Instruction PDF | Instruction Video | Engineer Cert | Fire Retardant Report Poly | Water Penetration Report | UV Protection Report Poly
Specifications: Aluminium Frame & Connectors | Hexagonal Shape Main Profile | Leg Profile 57x 50 x 2mm | Truss Bars 36 x 18 x 2mm | Height 3.3m | Clearance 2.05m | Frame Weight 36kg | Poly Roof Weight 9kg | PVC Roof Weight 15kg | Box Dimensions 163 x 46 x 34cm
Warranty: Frame 10 Years | Polyester Fabric 1 Year | UV Fabric 2 Years | PVC Fabric Plain 5 Years | PVC Fabric Printed 2 Years
Resources: Specification Sheet | Artwork Template | Instruction PDF | Instructions Video | Engineer Cert | Fire Retardant Report Poly | Fire Retardant Report PVC | Water Penetration Report | UV Protection Report Poly | UV Protection Report PVC
Specifications: Aluminium Frame & Connectors | Hexagonal Shape Main Profile | Leg Profile 50 x 45 x 1.5mm | Truss Bars 33 x 15 x 1422mm | Height 3.29m | Clearance 2m | Frame Weight 35kg | Poly Roof Weight 9kg | PVC Roof Weight 15kg | Box Dimensions 156 x 45 x 32cm
Warranty: Frame 10 Years | Polyester Fabric 1 Year | UV Fabric 2 Years | PVC Fabric Plain 5 Years | PVC Fabric Printed 2 Years
Resources: Specification Sheet | Artwork Template | Instruction PDF | Engineer Cert | Q8 Wall Options | Fire Retardant Report Poly | Fire Retardant Report PVC | Water Penetration Report | UV Protection Report Poly | UV Protection Report PVC
Specifications: Aluminium Frame & Connectors | Square Shape Main Profile | Leg Profile 40 x 40 x 2mm | Truss Bars 32 x 16 x 1415mm | Height 3.29m | Clearance 2m | Frame Weight 33kg | Poly Roof Weight 9kg | PVC Roof Weight 15kg | Box Dimensions 163 x 39x 28cm
Warranty: Frame 7 Years | Polyester Fabric 1 Year | UV Fabric 2 Years | PVC Fabric Plain 5 Years | PVC Fabric Printed 2 Years
Resources: Specification Sheet | Artwork Template | Instruction PDF | Instruction Video | Engineer Cert | Fire Retardant Report Poly | Fire Retardant Report PVC | Water Penetration Report | UV Protection Report Poly | UV Protection Report PVC
Custom Printing
We offer custom printing on a wide range of products. Don’t forget to checkout our available print packages!
Print Package 1
1 x Valance Panel Print
Print Package 2
4 x Valance Panel Print
Print Package 3
1 x Valance Panel Print
1 x Roof Panel Print
Print Package 4
4 x Valance Panel print
4 x Roof Panel Print
Print Package 1
1 x Valance Panel Print
Print Package 2
4 x Valance Panel Print
Print Package 3
1 x Valance Panel Print
1 x Roof Panel Print
Print Package 4
4 x Valance Panel print
4 x Roof Panel Print
Sublimation Printing
Sublimation printing, also known as dye sublimation printing involves the use of a digital printer to produce a print on sublimation transfer paper. The sublimation paper is then placed into a heat press with the marquee fabric and exposed to a temperature of 200 degrees celsius. The artwork is then transferred from the paper to the marquee fabric.
600D PU Coated Polyester, Fabric 245GSM, Sewn with Fabric Binding, Matte print finish.
LED-UV Printing
UV printing is a form of digital printing that uses ultra-violet lights to dry or cure ink as it is printed. As the printer distributes ink on the surface of the marquee fabric, specially designed UV lights follow close behind, “curing” or “drying” the ink instantly.
900D PU Coated Polyester, Ultra-violet light printing, Sewn with fabric binding, Clear protective seal, Print finish semi gloss.
Digital Printing
Large format digital printing refers to method of printing from a digital based image directly to the PVC marquee material.
Once the print has dried a hot lacquer is applied to the print surface to seal the print to avoid scratches.
580gsm PVC, Large format digital printing, Heat welded seams, Hot lacquer, Print finish glossy
Available Fabrics
500D PVC Coated Polyester
Available for Plain products
Specifications
100% Polyester with PVC backing
Yarn count: 500D x 500D
Weight: 280 gsm
Colourfastness to light 5-6 En
Features
1 year warranty
Waterproof
Fire, UV & Wind resistant
PVC reinforced Corners
600D PU Coated Polyester
Available for Custom Printed products
Specifications
100% Polyester with PU backing
Yarn count: 600D x 600D
Weight: 245 gsm
Colourfastness to light 5-6 En
Features
1 year warranty
Fire, UV and wind resistant
Waterproof
PVC Reinforced Corners
Black or White reverse fabric
Dye Sublimation Printing
Dye sublimation printing involves the use of a digital printer to produce a print on sublimation transfer paper. The sublimation paper is then placed into a heat press with the fabric and exposed to a temperature of 200 degrees Celsius. The artwork is then transferred from the paper to the fabric. The fabric has the artwork embedded in the material and the design will not scratch from the surface. The fabric has a matte finish, which photographs well and suits indoor and outdoor use.
580 GSM PVC
Available for Plain and Custom Printed products
NOT AVILABLE FOR X5 and X6 RANGE MARQUEES
Specifications:
100% PVC
Weight: 580 gsm
Colourfastness to light: 5-6 En standard
Features:
2 year warranty printed
5 year warranty plain
Waterproof
Fire, UV & Wind resistant
Hot lacquer welded seams
Digital Print Process
Large format digital printing refers to method of printing from a digital based image directly to the PVC material. Once the print has dried a hot lacquer is applied to the print surface to seal the print to avoid scratches.
Instruction Videos
Learn how to set up your Marquee correctly and safely by watching our instruction videos!
Marquee Accessories
Enhance your Folding Marquee with accessories and weights!
